Novel Approach to the Diagnosis of Fractures in an Austere Environment Using a Stethoscope and a Cellular Phone

Introduction

Healthcare providers practicing outside of the hospital setting, such as those participating in expeditionary, sports, or battlefield medicine, are often presented with diagnostic dilemmas. One such dilemma is the accurate diagnosis and disposition of musculoskeletal injuries. These practitioners have a wide range in skill levels and often work in remote locations where they must independently make evacuation and treatment decisions under challenging conditions. They are in constant need of simple, effective, and easily learned diagnostic techniques.

The evaluation of fractures rests mostly on the physical examination. However, beyond the traditional examination, it is sometimes taught that a fracture can be detected using a 128 Hz tuning fork and a stethoscope. The technique involves placing the vibrating tuning fork distal to the injury and auscultating proximally. Bone with cortical disruption results in a decrease in the sound propagation. Several studies have demonstrated the value of this technique. ^{1 –}4 To minimize the equipment carried by practitioners in an austere environment, we propose changing the vibration source to a more commonly carried tool, a cellular telephone. In this pilot study, we demonstrate a novel approach to the diagnosis of fractures in the humerus and femur using a cellular phone and stethoscope.

Methods

Using 2 cadavers, fractures were made in 1 humerus and 1 femur each. One additional body was used as a control. Fractures were produced with the combined use of a bone saw, hammer, and chisel. A variety of fracture sizes and types were produced including transverse, oblique, and comminuted. Fractures of the humerus were done at the surgical neck whereas the femur fractures were produced just distal to the lesser trochanter. All limbs had the same incision made, to blind the participants. A convenience sample of 27 emergency medicine residents and 1 emergency medicine attending physician performed the diagnostic examination.

The participants had never used the study technique nor had they used the tuning fork technique before their participation in this study. There were no known hearing deficits among the participants. For the femur, participants were asked to auscultate at the pubic symphysis and decide which side was decreased: left, right, or neither (Figure 1). For the humerus, participants were asked to auscultate at the anterior shoulder and decide which side was decreased: left, right, or neither (Figure 2). The researcher held the vibrating cell phone to the patella for the lower extremities (Figure 3) and to the lateral epicondyle for the upper extremities (Figure 4). The sites of vibration and auscultation resemble previous studies done with the tuning fork technique. Duration of contact was approximately 3 s per side. The participants were able to request repeats on either side until confident in their examination. To limit amplitude variability, the phone was applied without a case, flush against the bony prominence, with no downward or lateral pressure. The participants were blinded as to which limbs were fractured.

OPEN IN VIEWER

Figure 1

Femur auscultation site at the pubis. (Personal protective equipment excluded for demonstration purposes.)

OPEN IN VIEWER

Figure 2

Humerus auscultation site at the anterior shoulder. (Personal protective equipment excluded for demonstration purposes.)

OPEN IN VIEWER

Figure 3

Femur vibration site at the patella. (Personal protective equipment excluded for demonstration purposes.)

OPEN IN VIEWER

Figure 4

Humerus vibration site at the lateral epicondyle. (Personal protective equipment excluded for demonstration purposes.)

For this study, we used the Apple iPhone 3S (Apple, Cuppertino, CA) and the Littmann Master Classic II Stethoscope (3M Health Care, St. Paul, MN). To make the phone vibrate repeatedly, the iVibe application was used (Robot Mouse, West Chester, PA). Measures of diagnostic accuracy were calculated using GraphPad Prism version 5.04 for Windows (GraphPad Software, San Diego, CA; www.graphpad.com). This study was exempt from the Institutional Review Board at the University of Texas Health Science Center at Houston.

Results

The study included 3 cadaver models and 28 participants, including 27 emergency medicine residents of all year groups and 1 emergency medicine attending physician. Among the 3 cadaver models there were 2 fractured humeri and 2 fractured femurs. Each participant examined 12 extremities, resulting in 336 total examinations (Table 1). Overall, the use of the cellular phone and stethoscope resulted in a sensitivity of 73% (95% confidence interval [CI]: 0.64 to 0.81) and a specificity of 83% (95% CI: 0.77 to 0.88), with a positive predictive value of 68% (95% CI: 0.59 to 0.77), a negative predictive value of 86% (95% CI: 0.81 to 0.90), a positive likelihood ratio of 4.3, and a negative likelihood ratio of 0.32 (Table 2).

Discussion

The use of tuning forks to auscultate fractures has been studied several times in the past ^{1 –}4 and found to be moderately sensitive and specific. Bache and Cross ¹ used a stethoscope and 128 Hz tuning fork to diagnose fractures of the femoral neck and shaft and found an accuracy of 87% for femoral neck fractures. Misurya et al ³ used a 128 Hz tuning fork and a pediatric stethoscope to diagnose fractures to the tibia and to the femoral neck and shaft. They were able to detect fractures in 94% of patients. Moore ⁴ used the same equipment on a wide array of bones from the femur to the clavicle and found an overall sensitivity of 83%, specificity of 80%, positive LR of 4.2, and a negative LR of 0.2 for the diagnosis of fractures. Jawad et al ² added an objective measurement by using a tuning fork and an electronic stethoscope to detect changes in amplitude, and found an accuracy of 80%. Among these studies, the reasons for inaccurate results included bilateral pubic rami fractures, chronic osteomyelitis, obesity, posterior hip fracture, fracture impaction, avulsion, and buckle fractures. ^{1 –}4 Our study found similar results with an overall sensitivity of 73% and specificity of 83% and a negative predictive value of 86%.

Conclusions

Although the tuning fork and stethoscope technique is taught to physicians participating in expeditionary medicine, few use it in practice. Medicine in the austere environment focuses on limiting equipment and using equipment with multiple uses. In this case, the tuning fork has limited utility. However, most expedition physicians will carry a stethoscope and a cell phone. The ability to diagnose fractures will aid in disposition and evacuation decisions. With a negative predictive value of 86%, if the physician does not hear a difference between the injured and uninjured extremity, evacuation could possibly be delayed. That is particularly important in the deployed environment where evacuation is both limited and dangerous. This method is a simple, cost-effective adjunct to the clinical examination.

In this study, we found an overall sensitivity of 73% and specificity of 83%. The next step is to utilize this method in the emergency department or orthopedic clinic to assess its accuracy for living tissue with a variety of fracture types and locations.
