Climate policy cost-benefit model application for successful Central European building retrofitting programs—A Hungarian case study

The traditional CBA

Today, the CBA has become a fundamental tool in business for examining the financial returns of investments. A prerequisite for starting any project is that decision-makers must be aware of how profitable an investment will be in the long run. Its principle is to monetize all effects regarding the project that could be a result of implementation. This makes it easier for upper management to make the right decisions by weighing the finance-based factors not only in advance to the project, but during the execution as well. However, over time this feature of the method has also become its greatest weakness: It has become apparent that the effects which cannot be expressed in monetary terms are not validated to the same degree during the initial decision-making process.

The term “externality” was already being used in the world of business: It refers to features that cannot be validated under market conditions. Thus, people who work on modern CBA strive to include these externalities into their systems as best as possible. ¹¹ The current models aim to enable the influencing factors to be expressed as monetary amounts as accurately as possible. This is called internalizing. This has become one of the most important aspects of modern CBAs. Since it is not enough to recognize these factors during the course of project implementation; they also have to be included in calculations before the projects are started. In lack of doing so, programs aimed at developments can easily be misled in directions that do not serve the development of the system which makes them detrimental initiatives. Thus, the task when performing an accurate CBA is to develop a structure that can provide a comprehensive picture of the surrounding business environment and its changes by assigning indicators to it. The methodological part of this article presents an applicable CBA methodology regarding the involvement of environmental externalities and elaborates on its interpretation to climate policy terms.

The basis of modern CBAs

When developing the methodological bases of the analysis, the present study mainly relied on an International Environmental Consultation Group’s (The COWI group) CBA methodology, ¹² which was deemed to introduce the best solution to internalize the externalities. Since they basically developed their cost-benefit model to evaluate EU funded initiatives, their method is widely accepted for interpreting the implementation costs and benefits of a project. It mainly deviates from traditional financial analyses because its core objective is not to maximize profits from a corporate approach. It rather focuses on integrating the indirect effects from a social and environmental perspective.

The method defines external effects as quantifiably manageable characteristics that have ratios and prices which can be estimated even though they are quite difficult to express in monetary terms. It is precisely for this reason that a fiscal correction naturally must be applied in a later phase of the analysis to improve the accuracy of this estimate. Otherwise, it can end up leading toward unrealistic directions. This primarily applies to correctly dealing with factors such as taxes, state support, and correcting market prices. By focusing on the proper consideration of externalities, the analysis in the present study also applied the COWI methodology logic. ¹² However, since this article deals with both climate and cost efficiency, the study system had to be augmented with factors suitable to measure the impact of the projects on the GHG balance. ¹³ As a result, the study used two versions in every scenario. Of these, the first was to use present regulations to define the direction future processes would take by following the recent trends. This was referred to as business as usual (BAU) since it contained no new tools for climate regulation. ¹⁴ In the second version, a climate-oriented project was run, including environmental regulations which are currently under consideration by policy makers. This made it possible to differentiate sector GHG emissions in lack of any climate policy interventions and changes from emissions due to the implementation of various climate policy measures. During the financial calculations of the apparent (positive and negative) externalities, the influence on GHG emissions of both the BAU and the “Project” scenarios was taken into account.

The effect on the GHG balance was measured by converting all GHGs in the sector to CO₂ equivalent (CO₂e) ¹⁵ according to the global practice.

The characteristics of the newly developed climate policy cost-benefit model

When developing the new climate policy CBA model, the goal was to create a structure that provides a suitable picture of the changes regarding the examined system and its effects on macro level. In addition to a cost-benefit-based method, the other principle was multi-targeting. This pattern was tailored to the EU’s climate policy goals, which are “increasing energy efficiency,” “the intensive expansion of renewable energy systems,” and “achieving the greatest possible GHG reduction.”

There are several schools for handling multi-targeting, although situations such as this are generally handled as single-targeted. The correction mostly comes later by taking each target into account one after the other. Contrary to this approach, the present study model included the implementation of various targets in its calculations. In certain cases, the mechanism even considered them as having been met by the given time in the future. To each of these, only one factor was assigned that would later be influenced. During the research, the obtained results were stored. Then, the study was repeated for every single case by modifying only one target at a time, ensuring the remainder stayed constant. The end of the analysis resulted in a set of solutions. Eventually, the outcome the measures that influenced the implementation of the best scenarios were chosen.

Based on the above, the study developed the following CBA equation (1) ¹² :

AI pv = − ( IC − DI ) ︸ Decision on development + ( AS − AC ︸ Effects of operations ± IE ︸ Indirect effects ± GHG i ) pv

1

where:

AI_pv = the present value of additional income.

The essence of the new CBA model is the “GHG_i” at the end of the equation, as it monetizes those externalities that the climate-oriented project created in the system. Since one of the targets of the analysis is measuring the success of projects that reduce GHGs, the accompanying benefits and disadvantages are also included in this point. The implementation of the three-tiered climate policy target system between 2020 and 2030 is also internalized mainly through this indicator. The importance of this time interval comes from its match with the next EU programming period and the next phase of the EU ETS. Considering the proximity of the starting date, it is quite urgent to conduct researches which would contribute to the strategic planning process. The next subsection therefore will present the way how the essential data have been gathered for the accurate analysis.

The data used

The National Building Energy Strategy ¹⁶ and the research conducted by the Central European University ¹⁷ provided us with a database for the environmental aspects of the study. Data pertaining to the ratio of the various building types in Hungary and the GHG emissions of these housing types were obtained from this database. Trends for the quantitative changes in time of these buildings were calculated on the basis of the Central Statistical Office’s chronological database.

The values of changes in GHG emissions were defined based on the emission units of allowance (EUA) quota values forecasted by the EU ETS. It is expedient to use the future EUA trend values provided by the EU Commission because they form a definitive development point for the EU’s climate policy, meaning that they also form the basis for climate policy interventions.

The model comprises the following main units:

Historical datasets

Scenario 1: The renovation of the building stock

The authors assumed two fundamental cases in Scenario 1: First, processes continue as per the present political and support systems, which literature refers to as “BAU.” In the other case (“Project version”), significant financial resources were allocated to the building sector in the interest of achieving robust decreases in building CO₂ emissions. The total area of the housing units changes at the same rate in both cases. According to the Project version, the energy use of old buildings (e.g. prefabricated apartment buildings) is rationalized. The ratio of renovated buildings that are however at the end of their life cycles increases significantly. This version follows the attributes of the deep retrofitting building strategy which is trending currently among European countries.

Carbon efficiency indices in Scenario 1

Figure 1 clearly shows that the building sector’s CO₂ balance is barely reduced as a result of the project implemented by the study. The outcome does not significantly deviate from the BAU variant that takes place on the basis of present tendencies. This measure is the most important of the carbon efficiency indices since this includes all GHG emissions that are related to the fulfillment of the sectoral climate targets. The poor performance of the illustrated indicator means that the present renovation strategy for the building sector does not lead to substantially beneficial climatic impacts.

OPEN IN VIEWER

Figure 1.

Developments in the building sector’s CO₂e emissions until 2030. CO₂e: carbon dioxide equivalent.

Figure 2 illustrates the process of changes in GHG emissions per square meter of housing unit until 2030. This also makes it apparent that merely renovating the buildings did not significantly contribute to the BAU version’s development, which in itself already resulted in a reduction.

OPEN IN VIEWER

Figure 2.

Developments in the sector’s average CO₂e efficiency until 2030. CO₂e: carbon dioxide equivalent.

Figure 3 illustrates the spreading of low-carbon technologies within the building sector. The essence of these technologies is that they are based on low environmental loads and GHG emissions. The building sector is basically a passive emitter, meaning that it uses energy generated by other sectors. This is the reason why this value stagnates; the case is the same for new buildings, as well. ^{18 –20} The main problem was posed by the previous two figures, which show that despite its success, the project was unable to greatly improve GHG emission reductions. Especially in comparison to the processes that are expected to take place anyway. The building renovation projects basically stabilize the old disadvantageous systems and thus impede the modernization of buildings.

OPEN IN VIEWER

Figure 3.

Changes in low-carbon technology ratios in the sector until 2030.

After examining carbon efficiency, the performance of the project’s finances should also be reviewed: Is the renovation of outdated buildings an investment that provides a return?

Financial return indices in Scenario 1

Figure 4 takes not only the investment’s net present value (NPV) into account; it also compares the cost-benefit elements of the BAU and Project variants. In the case of a project of this magnitude, it is well known beforehand that a return can only be expected in the long term, for which reason the duration of the analysis was extended until 2040. However, Figure 5 shows that in case of implementing the project, the tendency of providing a return is quite slow and would only be realized in the distant future (far exceeding the life cycle of the investment, which thus ends up being a negative externality).

OPEN IN VIEWER

Figure 4.

Calculation of the project’s cost-benefit additional income.

OPEN IN VIEWER

Figure 5.

The project’s internal rate of return.

Figure 5 illustrates the internal rate of return (IRR), where the negative results are not necessarily bad, since the value is between 0% and −10%. If all other indices produce good values, the IRR value indicates that the social losses resulting from project implementation are acceptable. Thus, the project can be financed from EU funds.

However, the benefit-cost ratio (BCR) indicated in Figure 6 unequivocally suggests that the project should be cancelled. BCR1 shows the ratio of the project’s total costs to its total benefits and BCR2 shows how many times over the investment will provide a return during the program life cycle. In the best case, both values are over 1.0. The implementation should be taken into consideration if the value is between 0.5 and 1.0. However, if the value is less than 0.5, project implementation can result in serious deadweight losses for the society.

OPEN IN VIEWER

Figure 6.

The project’s benefit-cost ratios.

Evaluation of Scenario 1

The carbon orientation matrix (Figure 7) presents a summary of the study performed in the first scenario. It shows the processes that took place within the sector after project implementation during the studied period (in the present case: until 2040). Project characteristics are indicated by the blue bubble, depending on whether the investment ended up starting to give a return and whether the results led to a decrease (−) or to a surplus (+) regarding the sector’s emissions. Although the GHG reduction was not significant and the investment provided a return only very slowly, both factors are characterized by a slow improvement over the long term (NPV, carbon balance). This is the reason why the project was placed in the bottom right in the study matrix. It means that the building retrofitting strategy proved to be acceptable, even if only by weak numbers.

OPEN IN VIEWER

Figure 7.

Scenario 1 carbon orientation matrix.

Thus, if the subsequent scenario (concerning the construction of new buildings instead of renovating old ones) also shows similar tendencies, the difference between the efficiency of the two will determine which is preferred for implementation.

Explanation

− +: A project is implemented that increases emissions and the investment does not provide a return within a foreseeable amount of time.

+ +: A project where the invested costs show a tendency of providing a return, but the activity itself was not suitable for decreasing GHG emissions.

−−: Emissions can only be decreased with high costs on which there will be no return.

+ −: Acceptable scenarios that enable CO₂e decreases to be attained while also providing a return on investments over a longer period of time. (Investments that are recoverable even after their life cycles, with externalities that can change in line with political preferences.)

Scenario 2: Updating the building stock with new buildings

In the second scenario, the number of housing units and the change in their area is entirely the same as the indices in the previous scenario. The difference between the two cases is merely that the renovation of the buildings is not considered at all. Instead, this scenario assumes a process in which only new building units are constructed instead of renovating existing buildings.

Carbon efficiency indices in Scenario 2

Contrary to the first scenario, the improvement in the GHG emission indices is unequivocal in the case of the construction of new buildings (Figures 8 and 9). Figure 10 remained the same only because of the previously mentioned passive nature of the sector. In addition, although the project is already effective in short term, it will result in even greater reductions after 2030. Even though its CO₂e efficiency improvement per square meter is not that significant, this index is still more advantageous than in the previous scenario.

OPEN IN VIEWER

Figure 8.

Developments in the sector’s CO₂e emissions until 2030. CO₂e: carbon dioxide equivalent.

OPEN IN VIEWER

Figure 9.

Developments in the industry’s average CO₂e efficiency until 2030. CO₂e: carbon dioxide equivalent.

OPEN IN VIEWER

Figure 10.

Changes in low-carbon technology ratios in the industry until 2030.

Financial return indices in Scenario 2

With regard to finances (Figures 11 to 13), this project clearly provides the best results among the studied projects. It has already been discussed above that an initiative of such magnitude cannot provide positive NPV results while the investments are still under way (until 2030). But, if we examine the return processes that take place subsequently, the picture is much more positive.

OPEN IN VIEWER

Figure 11.

The additional income present value in the project’s cost-benefit calculation.

OPEN IN VIEWER

Figure 12.

The project’s internal rate of return.

OPEN IN VIEWER

Figure 13.

The project’s benefit-cost ratios.

The IRR diagram is naturally still negative since it does not assume a return within the studied period. Still, the BCR values indicate that more beneficial financial processes could take place in the long term (Figures 12 and 13).

Evaluation of Scenario 2

Although the results (blue bubble) of the summary figure (Figure 14) are similar in the present scenario as in the previous one (+−), the rate of the processes (return, emission reductions) also must be taken into account. Apparently, it is significantly more advantageous this time around. It has already been noted that in the case of a project of this magnitude (1.746 billion Hungarian Forints (HUF)), a long-term return is natural due to the high investment costs. However, the fact is that tendencies are much more positive in this case than in the scenario realizing the simple retrofitting strategy. Since the return time is shorter and the GHG reduction rate is also significantly more efficient, it can be stated that relying on newly built buildings leads to a more viable decision in the terms of economy and environment.

OPEN IN VIEWER

Figure 14.

Scenario 2 carbon orientation matrix.
