As a result of failures uncovered after the Northridge earthquake, the AISC Seismic Provisions for Structural Steel Buildings has become extremely stringent in its design provisions for moment frame structures. Although the changes are justified, they are not necessary for every type of building system. Some structures can be safely designed to resist earthquake forces elastically without concern of structural collapse. Metal buildings are typically lightweight, and small inertia forces from the design earthquake will not usually result in an inelastic response of a system that is properly designed to resist wind forces. In this paper, metal building systems are analyzed using an equivalent lateral force method and a linear time history analysis to show that typical metal building systems will respond elastically to the design earthquake. Specifically, using the International Building Code along with the aforementioned document, it is shown in the following sections that for lightweight metal building structures, adherence to the AISC Seismic Provisions for Structural Steel Buildings is not required in most cases except for locations on the West Coast and a few regions east of the Rocky Mountains. Elastic design methodology is discussed and design recommendations applicable to metal building systems are provided.

Direct displacement-based design requires a simplified procedure to estimate the seismic deformation of an inelastic SDF system, representing the first (elastic) mode of vibration of the structure. This step is usually accomplished by analysis of an “equivalent” linear system using elastic design spectra. In this paper, an equally simple procedure is developed that is based on the well-known concepts of inelastic design spectra. We demonstrate that the procedure provides the following: (1) accurate values of displacement and ductility demands, and (2) a structural design that satisfies the design criteria for allowable plastic rotation. In contrast, the existing procedure using elastic design spectra for equivalent linear systems in shown to underestimate significantly the displacement and ductility demands. The existing procedure is shown to be deficient in yet another sense; the acceptable value of the plastic rotation, leaving an erroneous impression that the allowable plastic rotation constraint has been satisfied.

A simplified empirically based seismic site response evaluation procedure that includes measures of the dynamic stiffness of the surficial materials and the depth to bedrock as primary parameters is introduced. This geotechnical site classification scheme provides an alternative to geologic-based and shear wave velocity-based site classification schemes. The proposed scheme is used to analyze the ground motion data from the 1989 Loma Prieta and 1994 Northridge earthquakes. Period-dependent and intensity-dependent spectral acceleration amplification factors for different site conditions are presented. The proposed scheme results in a significant reduction in standard error when compared with a simpler “rock vs. soil” classification system. Moreover, results show that sites previously grouped as “rock” should be subdivided as competent rock sites and weathered soft rock/shallow stiff soil sites to reduce uncertainty in defining site-dependent ground motions. Results also show that soil depth is an important parameter in estimating seismic site response. The standard errors resulting from the proposed site classification system are comparable with those obtained using the more elaborate code-based average shear-wave velocity classification system.

Potential damage assessment is fundamental for defining mitigation procedures and risk management strategies. Damage assessment involves the difficulties of defining, assessing, and modeling the variables involved, as well as handling uncertainty. Seismic damage estimation of structures does not only depend on the behavior of the structural system, but it involves other factors, which differ in nature. The paper presents a methodology for damage assessment of structures that combines systems theory, fuzzy logic, and neural networks. A feed-forward neural network supported on the systemic organization of information is used to assess the expected structural damage for a given earthquake. The methodology provides a very useful environment to consider the context of the building structure. The network has been trained using the damage observed in the recent earthquake that occurred in central Colombia. Several sets of structures were evaluated and the results compared to the damage observed. The model showed to be highly reliable and a good representation of experts' opinions. Computer software ERS-99 was developed and is currently being used for teaching and consulting purposes.

Probabilistic seismic hazard analyses were conducted to estimate both ground motion and fault displacement hazards at the potential geologic repository for spent nuclear fuel and high-level radioactive waste at Yucca Mountain, Nevada. The study is believed to be the largest and most comprehensive analyses ever conducted for ground-shaking hazard and is a first-of-a-kind assessment of probabilistic fault displacement hazard. The major emphasis of the study was on the quantification of epistemic uncertainty. Six teams of three experts performed seismic source and fault displacement evaluations, and seven individual experts provided ground motion evaluations. State-of-the-practice expert elicitation processes involving structured workshops, consensus identification of parameters and issues to be evaluated, common sharing of data and information, and open exchanges about the basis for preliminary interpretations were implemented. Ground-shaking hazard was computed for a hypothetical rock outcrop at -300 m, the depth of the potential waste emplacement drifts, at the designated design annual exceedance probabilities of 10^-3 and 10^-4. The fault displacement hazard was calculated at the design annual exceedance probabilities of 10^-4 and 10^-5.

This study was conducted to assess the level of adoption of nonstructural seismic hazard adjustments by hospitals in Southern California, and to identify the factors that lead to adoption of these adjustments. Results provide evidence that hospitals in Southern California have partially implemented a variety of earthquake preparedness and mitigation activities. However, many adjustments specific only to earthquake hazard were not commonly implemented, and this is cause for concern. Successful implementation of nonstructural measures is most likely to occur in large hospitals having government or not-for-profit ownership, high levels of perceived support for seismic risk reduction from upper administrators, and frequent interaction of the hospital disaster coordinator with those in similar roles at other organizations.
