Clinical Hemorheology and Microcirculation

The ability to evaluate tumor development within experimental oncology is of upmost importance. However, determining tumor volumes in 3D in vivo tumor models is challenging. The chick chorioallantoic membrane (CAM) model represents an optimized xenograft model that surpasses many disadvantages that are inherent to rodent models and provides the opportunity of real-time monitoring of tumor growth.

The objective of this study was to introduce a new method that enables monitoring of tumor growth within the CAM model throughout the course of the experiment.

Sarcoma cell lines and sarcoma primary tumors were grafted onto the CAM of fertilized chicken eggs. A digital microscope (Keyence VHX-6000) was used for 3D volume monitoring before and after tumor excision and compared it to tumor weight.

Accuracy of tumor volumes was validated through correlation with tumor weight. In and ex ovo tumor volumes correlated significantly with tumor weight values.

The described method can be used to assess the effects of chemotherapeutic agents on the growth of tumors that have been grafted onto the CAM and further advance personalized cancer therapy. In summary, we established a promising protocol that enables in vivo real-time tracking of tumor growth in the CAM model using a digital microscope.

Osteosarcomas are a rare, heterogeneous and malignant group of bone tumors that have a high potential for metastasis and aggressive growth patterns. Treatment of metastasized osteosarcoma is often insufficient and research is compromised by problems encountered when culturing cells or analyzing genetic alterations due to the high level of intratumoral and intertumoral heterogeneity. The chick chorioallantoic membrane (CAM) model, a 3D-in-vivo-tumor-model, could potentially facilitate the investigation of osteosarcoma heterogeneity at an individual and highly specified level.

Objective was to establish the grafting and transplantation of different primary osteosarcoma tissue parts onto several consecutive CAMs for tumor profiling and investigation of osteosarcoma heterogeneity.

Various parts of primary osteosarcoma tissue were grafted onto CAMs and were transplanted onto another CAM for five to seven consecutive times, enabling further experimental analyzes.

Primary osteosarcoma tissue parts exhibited satisfactory growth patterns and displayed angiogenic development on the CAM. It was possible to graft and transplant different tumor parts several times while the tissue viability was still high and tumor profiling was performed.

Primary osteosarcoma tissue grew on several different CAMs for an extended time period and neovascularization of serial transplanted tumor parts was observed, improving the versatility of the 3D-in-vivo-tumor-model.

To evaluate the use of dynamic contrast enhanced ultrasound (CEUS) with parametric color-coded imaging and time intensity curve analysis (TIC) for planning and follow-up after prostate arterial embolization (PAE).

Before and after selective iliacal embolization by PAE with a follow up of 6 months 18 male patients (43–78 years, mean 63±3.5 years) with histopathological proven benign prostate hyperplasia were examined by one experienced examiner. A multifrequency high resolution probe (1–6 MHz) was used for transabdominal ultrasound and CEUS with bolus injections of 2.4 ml sulphur-hexafluoride microbubbles. Independent evaluation of color-coded parametric imaging before and after PAE by in PACS stored DICOM loops from arterial phase (10–15 s) up to 1min were performed. Criteria for successful treatment were reduction of early arterial enhancement by changes of time to peak (TTP) and area under the curve (AUC) by measurements in 8 regions of interest (ROI) of 5 mm in diameter at the margin and in the center and changes from hyperenhancement in parametric imaging (perfusion evaluation of arterial enhancement over 15 s) from red and yellow to blue and green by partial infarctions. Reference imaging method was the contrast high resolution 3 tesla magnetic resonance tomography (MRI) using 3D vibe sequences before and after PAE and for the follow up after 3 and 6 months.

PAE was technically and clinically successful in all 18 patients with less clinical symptoms and reduction of the gland volume. In all cases color-coded CEUS parametric imaging was able to evaluate partial infarction after embolization with changes from red and yellow to green and blue colors in the embolization areas. Relevant changes could be evaluated for TIC-analysis of CEUS with reduced arterial enhancement in the arterial phase and prolonged enhancement of up to 1 min with significant changes (p = 0.0024). The area under the curve (AUC) decreased from 676±255.04 rU (160 rU–1049 rU) before PAE to 370.43±255.19 rU (45 rU–858 rU) after PAE. Time to peak (TTP) did not change significantly (p = 0.6877); TTP before PAE was 25.82±9.04 s (12.3 s–42.5 s) and after PAE 24.43±9.10 s (12–39 s). Prostate volume decreased significantly (p = 0.0045) from 86.93±34.98 ml (30–139 ml) before PAE to 50.57±26.26 ml (19–117 ml) after PAE. There were no major complications and, in most cases (14/18) a volume reduction of the benign prostate hyperplasia occurred.

Performed by an experienced examiner CEUS with parametric imaging and TIC-analysis is highly useful to further establish prostatic artery embolization (PAE) as a successful minimal invasive treatment of benign prostatic hyperplasia.

HCC is the most frequent primary liver cancer entity. Major risk factors comprise chronic HBC and HCV infections, ALD or NAFLD. Apart from the anamnesis, the clinical examination and serologic analysis, an essential part of the diagnostic HCC work-up is due to imaging findings from sonography, CT or MRI scans. HCC lesions feature a distinct vascularization pattern: hyperenhancement during early arterial and hypoenhancement/wash-out during portal venous or delayed phases. CEUS facilitates dynamic assessment of microperfusion patterns of suspicious liver lesions.

The purpose of the present retrospective single-center study was to determine the diagnostic value of CEUS for assessing HCC by comparison with findings from MRI scans.

Between 2004-2018 292 patients with suspicious liver lesions underwent CEUS and MRI. All patients underwent native B-mode, Color Doppler and CEUS after given informed consent. The applied contrast agent was a second-generation blood pool agent (SonoVue®, Bracco, Milan, Italy). Every CEUS examination was performed and interpreted by a single experienced radiologist (EFSUMB Level 3).

CEUS was performed on all included patients without occurrence of any adverse effects. CEUS showed a sensitivity of 96%, a specificity of 91%, a PPV of 95% and a NPV of 94% for analyzing HCC in comparison with MRI as the diagnostic gold standard.

With a distinguished safety profile CEUS shows a high diagnostic accuracy in assessing HCC compared to corresponding results from MRI scans.

Percutaneous sclerotherapy is a well-established treatment option for venous malformations (VM). A recently established sclerosing agent is ethanol-gel. Aim of this study was to identify, if contrast-enhanced ultrasound (CEUS) with an integrated perfusion analysis allows for differentiation between untreated VM, healthy tissue, and with gelified ethanol treated malformation tissue.

In this institutional review board approved prospective study symptomatic VM patients underwent CEUS at exactly the same position before and after sclerotherapy with ethanol-gel. Two experienced sonographers performed all examinations after the bolus injection of microbubbles using a multi-frequency probe with 6 –9 MHz of a high-end ultrasound machine. An integrated perfusion analysis was applied in the center of the VM and in healthy, surrounding tissue. For both regions peak enhancement (peak), time to peak (TTP), area under the curve (AUC), and mean transit time (MTT) were evaluated. Wilcoxon signed rank test was executed; p-values <0.05 were regarded statistically significant.

In 23 patients including children (mean age 25.3 years, 19 females) before treatment all identified parameters were significantly higher in the VM center compared to healthy tissue (peak: p < 0.01; TTP: p < 0.01; AUC: p < 0.01; MTT: p < 0.01). Comparing the VM center before and after treatment, TTP (p < 0.02) and MTT (p < 0.01) reduced significantly after sclerotherapy. In surrounding tissue only peak changed after treatment in comparison to pre-treatment results (p = 0.04). Comparing data in the VM center with surrounding tissue after sclerotherapy, results still differed significantly for peak (p < 0.01), TTP (p < 0.01), and AUC (p < 0.01), but assimilated for MTT (p = 0.07).

All with CEUS identified parameters seem to be excellent tools for differentiating between VM and healthy tissue. TTP and MTT could distinguish between with ethanol-gel sclerotized VM portions and untreated malformation parts and thereby might assist the monitoring of sclerotherapy with ethanol-gel.

Detecting local tumor recurrence from post-treatment changes in head and neck cancer (HNC) remains a challenge. Based on the hypothesis that post-therapeutically altered tissue is bradytroph, lower perfusion values are expected in perfusion CT (PCT) while higher perfusion values are expected in recurrent malignant tissue.

This prospective study investigates PCT for post-treatment recurrent HNC detection with a maximum slope algorithm.

A total of 80 patients who received PCT of the head and neck for post-therapy follow-up, of which 63 had no tumor recurrence and 17 presented a histopathologically confirmed recurrence were examined. Regions of interest were placed in the location of the initial tumor, in reference ipsilateral nuchal muscle tissue and the corresponding internal carotid artery. Perfusion was calculated using a single-input maximum slope algorithm.

With PCT, recurrent HNC can be differentiated from post-treatment tissue (p < 0.05). It further allows delineating recurrent tumor tissue from benign nuchal tissue of reference (p < 0.05). PCT data of patients with and without recurrent HNC are comparable as perfusion values of reference tissues in patients with and without HNC do not differ (p > 0.05).

PCT in combination with a commercially available maximum slope algorithm offers radiologists a reliable imaging tool to detect recurrent head and neck cancer within post-therapeutically altered tissue.

The pharyngeal reconstruction is a challenging aspect after pharyngeal tumor resection. The pharyngeal passage has to be restored to enable oral alimentation and speech rehabilitation. Several techniques like local transposition of skin, mucosa and/or muscle, regional flaps and free vascularized flaps have been developed to reconstruct pharyngeal defects following surgery, in order to restore function and aesthetics. The reconstruction of the pharynx by degradable, multifunctional polymeric materials would be a novel therapeutical option in head and neck surgery.

Samples of an ethylene-oxide sterilized polymer (diameter 10 mm, 200μm thick) were implanted for the reconstruction of a standardized defect of the gastric wall in rats in a prospective study. The stomach is a model for a “worst case” application site to test the stability of the implant material under extreme chemical, enzymatical, bacterial, and mechanical load.

Fundamental parameters investigated in this animal model were a local tight closure between the polymer and surrounding tissues, histological findings of tissue regeneration and systemic responses to inflammation. A tight anastomosis between the polymer and the adjacent stomach wall was found in all animals after polymer implantation (n = 42). Histologically, a regeneration with glandular epithelium was found in the polymer group. No differences in the systemic responses to inflammation were found between the polymer group (n = 42) and the control group (n = 21) with primary wound closure of the defect of the gastric wall.

A sufficient stability of the polymeric material is a requirement for the pharyngeal reconstruction with implant materials.

Popliteal artery aneurysms (PAA) are the most common peripheral artery aneurysms. Most common cause is arteriosclerosis. Acute thromboembolic limb ischemia and rupture of the PAA depict severe complications. Diagnostic tools for identifying PAAs are (Doppler) ultrasound, CT/MR angiography and DSA.

The aim of the present retrospective single-center study is to assess the application and safety of CEUS for assessing untreated and treated PAAs.

13 patients were included in this study on whom CEUS was performed between 2007–2016. CEUS examinations were performed and interpreted by an experienced single radiologist (EFSUMB Level 3).

CEUS allowed for the detection of PAAs in all cases. CEUS allowed for detection of partial thrombosis of PAA in 7/8 of untreated patients, proper exclusion of PAA upon femoro-popliteal bypass in 3 patients, incomplete exclusion of PAA upon femoro-popliteal bypass in 1 patient and ruling out of in-stent stenosis in 1 patient.

CEUS is a useful and safe tool for in real-time evaluation of PAAs in the pre-/post-treatment status. In addition to conventional (Doppler) ultrasound and as an alternative tool to more elaborate imaging modalities, CEUS might be integrated in the future diagnostic work-up and follow-up of PAA patients.

Transesophageal echocardiography (TEE) as a guiding tool for edge-to-edge transcatheter tricuspid valve repair (EETVr) using MitraClip (Abbott Vascular, Santa Clara, USA) may not offer sufficient image quality in a significant proportion of patients.

Intracardiac echocardiography (ICE) as additional guiding tool in EETVr with the MitraClip device.

Appropriate angulations of the ICE catheter to visualize each commissure of the tricuspid valve were established in 3D printed heart models. In a single tertiary-care center ICE was used to support EETVr as additional guidance when TEE image quality was insufficient. Procedural safety and outcomes up to 30-days were compared between ICE/TEE and TEE only guided patients.

In 6 of 11 patients (54.5%) undergoing EETVr with MitraClip TEE alone was unsatisfactory, necessitating additional ICE guidance. In 4 of these 6 patients ICE enabled a successful completion of the procedure. The steering maneuvers identified in the 3D models were well applicable in all patients, providing examples for potential future ICE implementation in EETVr. Under both TEE alone (n = 5) and ICE (n = 6) guidance the rate of procedural complications was 0%. According to vena contracta values at discharge significant TR reduction was achievable in the treated cohort (p = 0.011). At 30-days follow-up one patient (ICE guided) died following global heart failure, not associated with the procedure itself.

ICE guidance may offer an additional tool to guide EETVr with the MitraClip device in patients with poor TEE quality, as it enables successful results without impairing procedural safety.

The aim of our pilot study is to consider if the new flow presentation of the vector flow (V-flow) allows an assessment of the valve morphology of the crosses with respect to an insufficiency.

We performed a total of 50 investigations in which we documented a complete valve closure at the so called “crosse” at the valve of the large saphenous vein, a delayed valve closure or an incomplete valve closure with consecutive insufficiency at the crosse. The valve function of the crosse is crucial for the development of varicosis. For our study we recorded age and gender of the patients. One patient in the study was suffering from Covid19. For the examinations we used a 3–9 MHz probe and a high-end ultrasound device. The examination was performed in a lying position and under quiet conditions. Before examination we practiced inhalation and exhalation as well as “pressing” or coughing with the patients, which resulted in a physiological closure of the venous valves. To rule out thrombosis, we carried out compression sonography on the legs. During the examination we documented the B-scan, the Color-Coded Duplex Sonography, the HR-flow and the V-flow for 3 seconds at the estuary of the crosses and incorporated these parameters into our measurements. Via V-flow, vectors can be imaged by representing the flow of erythrocytes and visually indicate a possible insufficiency due to delayed or incomplete valve closure.

31 of 50 patients (age 19–81years) showed a complete valve closure of the crosses, three of them suffered from thrombosis. In eight of the 50 study participants (age 45–79 years) a delayed valve closure could be diagnosed by V-flow within 1–2 seconds. None of them had a thrombosis, but six of them suffered from cancer. In eleven patients we derived an incomplete valve closure with insufficiency (age 51–88 years). With reflux it took >2 seconds to close the valve. The patient with Covid19 also showed an incomplete valve closure with insufficiency. At the same time this patient showed a Covid19-associated deep vein thrombosis. Eight additional patients also had a thrombosis. Six of them suffered from cancer. Overall, the results were best visualized by V-Flow.

The crosse as a significant venous structure can be well investigated by V-flow with respect to hemodynamic changes and a resulted reflux. Also associated changes close to the valve can be visualized well.

In recent years, follow-up after breast reconstruction with silicone implants and the detection of complications have been relieved by the possibility of improved diagnostic methods.

Between January 2015 and December 2019 a total of 40 patients (29–84 years) with silicone implants were included in this retrospective study. The implants were examined clinically and with modern imaging: general ultrasound imaging (US), magnetic resonance imaging (MRI), high resolution computed tomography (CT) and positron emission tomography –computed tomography (PET-CT). If necessary, a histological/cytological sample was taken. The breast implants were assessed by three radiologists specialized in breast imaging. The grade of capsular contracture was classified according to the Baker classification.

All 40 women obtained a clinical examination and an US diagnostic to identify early and more common complications such as implant folding and capsular fibrosis. Depending on the clinical examination and ultrasound findings additional MRI (n = 10), CT (n = 9) and/or PET-CT (n = 2) were performed. 16 patients had implants folding proven with US (n = 16), MRI (n = 6) and CT (n = 1). The grade of capsular fibrosis was determined according to the Baker classification. The following results were obtained in our study: 25 breast implants with Baker grade I and eleven breast implants with Baker grade II, both proven with US; one breast implants with Baker grade III and one breast implant with Baker grade IV, proven with US (n = 2), MRI (n = 1) and CT (n = 1). One patient had intracapsular rupture and one patient had extracapsular rupture, both detected on CT and surgically proven. No patient had a silicone accumulation in the lymph nodes. One patient had pathologically enlarged axillary lymph nodes, which were evaluated as inflammatory changes in PET-CT. Long-term complications such as the development of malignant breast tumors could not be observed.

To detect early complications after breast implant surgery, a regular clinical examination is indispensable. Imaging methods complement each other and if they are used multimodal, it is easier to identify early complications. Modern diagnostic modalities like ultrasound and magnetic resonance imaging expand the spectrum and improve diagnostic safety.

Sepsis is the result of a dysregulated host immune response to an infection. An ideal therapy would target both the underlying infection and the dysregulated immune response. DIBI, a novel iron-binding polymer, was specifically developed as an antimicrobial agent and has also demonstrated in vivo anti-inflammatory properties.

This study aimed to further investigate the effects of DIBI with and without the antibiotic imipenem (IMI) in colon ascendens stent peritonitis (CASP)-induced experimental sepsis.

Vehicle, DIBI and/or IMI were administered in C57BL/6 mice after CASP surgery. Intestinal leukocyte activation and capillary perfusion was evaluated by intravital microscopy. Moreover, bacterial load in peritoneal lavage fluid and blood, and plasma cytokine levels were assessed. In a second series of experiments, surgery to repair the colon was performed at 5 hr and these mice were followed for long-term survival over 7 days.

DIBI reduced leukocyte adhesion, improved capillary blood flow, and decreased key plasma cytokines levels. DIBI also improved survival of infected mice and greatly improved IMI efficacy. Survivors treated with IMI and DIBI were found to be free of systemic infection.

DIBI has promising potential for sepsis treatment including its use as a sole or an adjunct therapeutic with antibiotics.

Diagnostic and risk stratification in intensive and emergency medicine must be fast, accurate, and reliable. The assessment of sublingual microcirculation is a promising tool for this purpose. However, its value is limited because the measurement is time-consuming in unstable patients. This proof-of-concept validation study examines the non-inferiority of a reduced frame rate in image acquisition regarding quality, measurement results, and time.

This prospective observational study included healthy volunteers. Sublingual measurement of microcirculation was performed using a sidestream dark field camera (SDF, MicroVision Medical®). Video-quality was evaluated with a modified MIQS (microcirculation image quality score). AVA 4.3C software calculated microcirculatory parameters.

Thirty-one volunteers were included. There was no impact of the frame rate on the time needed by the software algorithm to measure one video (4.5 ± 0.5 minutes) for AVA 4.3C. 86 frames per video provided non inferior video quality (MIQS 1.8 ± 0.7 for 86 frames versus MIQS 2.2 ± 0.6 for 215 frames, p < 0.05), equal results for all microcirculatory parameters, but did not result in an advantage in terms of speed. No complications occurred.

Video captures with 86 frames offer equal video quality and results for consensus parameters compared to 215 frames. However, there was no advantage regarding the time needed for the overall measurement procedure.

The coagulation status of burn patients is generally impaired and is a major factor of the deteriorating burn patients’ overall situation. In trauma and other patient groups, the differential diagnosis of coagulation impairment has been largely improved by the use of rotational thromboelastometry (ROTEM®). The aim of this prospective observational study was the differentiated observation of coagulopathy in severely burned patients using standard parameters and ROTEM® thrombelastometry during the relevant stages of burn disease.

Twelve patients that sustained at least 20% third degree burns of total body surface area (TBSA) were included in the study. Standard and ROTEM® coagulation analyses were performed on admission and then twice daily during the first 14 days following burn trauma.

Although the initial assessment of DIC was similar for both standard labs and ROTEM® measurements, more patients were detected to be in a state of worsening coagulation status for a longer time in ROTEM® than in standard measurements. In addition, one patient was rated in to be in decompensated DIC for 3 days according to ROTEM® measurements, while no patient was rated to be in a decompensated DIC based on standard parameters.

This study points towards a more complex picture and higher occurrence of DIC in burn patients when thrombelastometric measurements like ROTEM® are taken into account in addition to standard coagulation parameters.

Keratinocytes are exposed to a thermal gradient throughout epidermal layers in human skin depending on environmental temperatures.

Here, the effect of cyclic temperature changes (ΔT) on HaCaT cell behaviors was explored.

HaCaT cells were cultured at constant temperature (37 °C or 25 °C) or under ΔT conditions. The morphology, mechanics, cell cycle progression, proliferation, and lipid synthesis of HaCaT cells were determined.

ΔT conditions led to the inhomogeneous arrangement of the cytoskeleton in HaCaT cells, which resulted in enlarged size, rounder shape, and increased stiffness. Accumulation in the G2/M phase in the cell cycle, a decreased proliferation rate, and a delayed lipogenesis were detected in HaCaT cells cultured under ΔT conditions.

ΔT conditions resulted in the re-arrangement of the cytoskeleton in HaCaT cells, which showed similarity to the temperature-induced disassemble and re-assemble of cytoskeletons in keratinocyte in vivo. The altered cytoskeleton arrangement resulted in the cell enlargement and stiffening, which reflected the changes in cellular functions. The application of oscillatory temperature in the in vitro culture of keratinocytes provides a way to gain more insights into the role of skin in response to environmental stimuli and maintaining its homeostasis in vivo.

The formation of spheroids is tightly regulated by intrinsic cell-cell and cell-substrate interactions.

The chitosan (CS)-coating was applied to investigate the driven force directed the spheroid formation.

The effects of CS on cell functions were studied. Atomic force microscopy was employed to measure the cell- biomaterial interplay at single cell level.

HaCaT cells shifted from their flattened sheet to a compact 3D spheroidal morphology when increasing CS-coating concentration. The proliferative capacity of HaCaT was preserved in the spheroid. The expression and activation of integrin β1 (ITGB1) were enhanced on CS modified surfaces, while the active to total ratio of ITGB1 was decreased. The adhesive force of a single HaCaT cell to the tissue culture plate (TCP) was 4.84±0.72 nN. It decreased on CS-coated surfaces as CS concentration increased, from 2.16±0.26 nN to 0.96±0.17 nN. The adhesive force between the single HaCaT cell to its neighbor cell increased as CS concentration increased, from 1.15±0.09 nN to 2.60±0.51 nN.

Conclusively, the decreased cell- substrate adhesion was the main driven force in the spheroid formation. This finding might serve as a design criterion for biomaterials facilitating the formation of epithelial spheroids.
